Szczegóły Produktu
Miejsce pochodzenia: Baoji, Chiny
Nazwa handlowa: LIHUA
Orzecznictwo: ISO9001, TUV etc.
Numer modelu: LH-TH
Warunki płatności i wysyłki
Minimalne zamówienie: 1 sztuk
Cena: US dollar $15/kg--US dollar $35/kg
Szczegóły pakowania: Pudełko ze sklejki na eksport
Czas dostawy: 5-25 dni roboczych
Zasady płatności: Akredytywa, T/T, Western Union
Możliwość Supply: 5000 kg miesięcznie
Product name: |
titanium forged ring |
Material: |
Gr5 |
Application: |
Chemical industry |
Outer diameter: |
200-1300mm |
Inner diameter: |
100-900mm |
Height: |
35-250mm |
Thickness: |
40-400mm |
Quality control: |
Ultrasonic Testing |
Product name: |
titanium forged ring |
Material: |
Gr5 |
Application: |
Chemical industry |
Outer diameter: |
200-1300mm |
Inner diameter: |
100-900mm |
Height: |
35-250mm |
Thickness: |
40-400mm |
Quality control: |
Ultrasonic Testing |
Titanium Aerospace Forging ASTM B381 Titanium Forgings
Mtaerials:Titanium GR2/ GR7/GR12/GR16
Dimension:As customer's requests and drawings
Technic:Forging+machining
Application:Heat exchangers/ pressure vessels for Petrochemical,Pharmeceutical and Food industry
Standard:ASTM B38/ASME SB381
The aerospace industry requires the highest standards for the forged products they use. From rockets to satellites, the need for reliable and durable forged parts has never been more prevalent.
Forging produces pieces that are stronger than an equivalent cast or machined part. As the metal is shaped during the forging process, the internal grain deforms to follow the general shape of the part. This results in a grain that is continuous throughout the part, resulting in its high strength characteristics. Forgings are broadly classified as either cold, warm or hot forgings, according to the temperature at which the processing is performed.
| Chemical requirements | |||||||||||
| N | C | H | Fe | O | Al | V | Pd | Mo | Ni | Ti | |
| Gr1 | 0.03 | 0.08 | 0.015 | 0.20 | 0.18 | / | / | / | / | / | bal |
| Gr2 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | / | / | bal |
| Gr5 | 0.05 | 0.08 | 0.015 | 0.40 | 0.20 | 5.5~6.75 | 3.5~4.5 | / | / | / | bal |
| Gr7 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | 0.12~0.25 | / | / | bal |
| Gr12 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | 0.2~0.4 | 0.6~0.9 | bal |
